Home > Product > Fume Hood > Fume Hood Fume Extraction Cabinet In the laboratory China

Fume Hood Fume Extraction Cabinet In the laboratory China

Fume cabinet China, also called fume extraction cabinet china. KOMAN only makes high-end and high-quality fume hood in the laboratory to ensure the health of the environment and laboratory personnel.


• Type: fume hood in the laboratory

• General Use: Commercial Furniture

• Material: All steel structure(1200/1500/1800*800*2350mm)

• Brand Name: KOMAN

• Product Name: fume cabinet China

• Color: Customized

• Work top: Epoxy Resin/ Phenolic Resin/Stainless Steel/Ceramic Work Top

• System: CAV/VAV system(Optional)

• Size: Customer Made

• Function: Chemistry Lab Room Furniture

• Certificate: ISO9001:2008/ ISO14001:2008/ SGS

• Size: Customized

• Packaging Details

• Inner Package: poly-foam & pearl-cotton between each separate parts

• One unit in one master carton

• Keyword: fume extraction cabinet china


External Size(W*D*H)1200 x 880 x 2350 mm1500 x 880 x 2350 mm1800 x 880 x 2350 mm
Internal Size(W*D*H)950 x 700 x 1150 mm1250 x 700 x 1150 mm1550 x 700 x 1150 mm
Work Surface Height850 mm850 mm850 mm
Exhaust air volume700-1300m³/h900-1700m³/h1300-2100m³/h
Air Velocity0.3 -- 0.6 m/s
Sash6mm tempered glass
Power SupplyAC110/220V, 50/60Hz(optional)
MaterialMain Body1.0mm, 1.2mm thickness cold-rolled steel with epoxy resin powder coating.
Inner liner Panel5mm thickness compact panel, acid and alkali resistance, temperature resistance and anti-moisture. (Ceramic/ glass fiber/ stainless steel/ PP/ etc optional )
WorktopStandard configuration for the epoxy resin worktop(with the edge of the water) (Phenolic resin, ceramic, stainless steel/ etc. optional)
Exhaust SystemDuctPVC duct system according to your piping layout
BlowerCentrifugal blower
SystemCAV/VAV system optional
AccessoryWater tap, water valve, gas tap, gas valve, PP cup sink optional
LED lamp*1
LCD control panel
Net Weight300kgs400kgs500kgs
