Biosafety cabinet airflow and biosafety clean bench adopts a tray structure, which is easy to remove and clean; the integrated sliding safety door can be arbitrarily positioned; the bracket and the upper box can be separated for easy handling. KOMAN is specialized in clean bench biosafety cabinet.
Description:
• Product name: biosafety clean bench
• Worktop: Stainless Steel
• Type: clean bench biosafety cabinet
• Function: Work station for all labs
• Dimension: 1200/1500/1800/2000*795*2050mm
• Working Dimension: 1004/1304/1604/1804*630*630mm
• Coating: Cold-rolled steel with anti-bacteria powder coating
• Weight: 260-400KGS
• Power Supply: AC220V/50Hz
• Cleanliness: ULPA: ISO Class4
• Filtration Efficiency: ULPA: ≥99.9995%
• Packaging Details: Wooden case
• Key word: biosafety cabinet airflow
Specifications:
| Model/Item | Parameter | |
| Nominal Size | 1.3meter(4') | |
| Filtration Efficiency | ULPA: ≥99.9995%, @0.12μm | |
| Downflow Velocity | 0.35 m/s(68.88fpm) | 0.33 m/s(64.94fpm) |
| Inflow Velocity | 0.55m/s(108.24fpm) | 0.53 m/s(104.30fpm) |
| Noise | 58~65 dB(A) | |
| Vibration | ≤5 μm(center of tabletop) | |
| Power Supply | AC220V,1φ,50Hz | |
| Opening Height | 200 mm | |
| Personnel Protection | A. Total colony in impaction sampler ≤10CFU./timeB. Total colony in impaction sampler ≤5CFU./time | |
| Product Protection | Total colony in culture dish ≤5CFU./time | |
| Cross-contamination Protection | Total colony in culture dish ≤2CFU./time | |
| Max Consumption(with spare socket) | 1.75 kVA | |
| Rated Power(without spare socket) | 0.43 kVA | |
| Weight | 300 kg | |
| Work Dimension (W1XD1XH1) | 1304*630*630 mm(51.3''x24.8''x24.8'') | |
| Overall Dimension(WXDXH) | 1500*795*2050 mm(59.1''x31.3''x80.7'') | |
| Size and Qty. of Light | LED 31 w x 1PC | |
| Size and Qty. of UV Light | 30 w x 1PC | |
| Lumin. | ≥900 Lx | |
| Cabinet Materials | High-grade steel and lacquered in ivory | |
| Working Area Materials | SS304 fully finished | |
| Air Direction | Top out | |
