Clean bench fume hood are clean bench for lab used in biological laboratories. The clean bench hood produced by KOMAN are designed and produced in strict accordance with the standards of NSF-49 and JG170-2005. Also use the microbiological method to evaluate the performance of clean bench fume hood.
Description:
• Type: clean bench fume hood
• General Use: School/Hospital lab
• Material: Metal
• Metal Type: Stainless Steel
• Place of Origin: Shenzhen, China
• Brand Name: KOMAN
• Product Name: clean bench for lab
• Application: Biology lab
• Structure: Steel Structure
• Air Cleanliness: ISO 5/Class 100
• Noise: ≤62dB(A)
• Air Velocity: 0.25-0.45m/s
• Illuminance: ≥650Lx
• HEPA Filter: 99.999% Efficiency
• Packaging Details: PP film&wooden carton
• Key word: clean bench hood
Specifications:
| Model/Item | 1000 | 1300 | 1600 | 1800 |
| Cleanliness | ISO CLASS 5 | |||
| Air velocity | 0.26~0.38 m/s (55.1~70.9fpm)(adjustable) | |||
| Noise | ≤62 dB(A) | |||
| Illumination | ≥650 Lx | |||
| Power supply | AC220V, 1φ, 50Hz | |||
| Consumption | 300 w | 600 w | 600 w | 600 w |
| Weight | 140 kg | 175 kg | 200 kg | 210 kg |
| Work Dimension | 1000x560x720 mm | 1300x560x720 mm | 1600x560x720 mm | 1800x560x720 mm |
| Overall Dimension | 1080x785x1820 mm | 1380x785x1820 mm | 1680x785x1820 mm | 1880x785x1820 mm |
| Size & No. HEPA Filter | 990x680x69 mmx1 set | 645x680x69 mm x2 sets | 795x680x69 mm x2 sets | 895x680x69 mm x2 sets |
| Light | LED 15w x 1pc | LED 24.5w x 1pc | LED 31w x 1pc | LED 36w x 1pc |
| UV Light (optional) | 18w x 1pc | 30w x 1pc | 36w x 1pc | 36w x 1pc |
| Materials | Working table: All-in-one Stainless Steel, Outside cabinet: high grade steel and lacquered in ivory | |||
| Optional: working area all ss304 | ||||
| Mode of Operation | single people/single side | double people/single side | ||
NOTE: Not include spare socket, the capacity of each units is 3A, each clean bench with 2 spare sockets.
